Tracing Bias Propagation Across Subgroups in Federated Learning

Tirathraj Ramburn, Afaf Taïk, Farnoosh Ghadiri · SMASH 2026 spotlightRead the paper ↗

From the abstract

We show that the impact of false-negative errors on recipient client–subgroup pairs can be predicted from the global model's curvature together with source and recipient-group feature summaries, without retraining a model for each possible error. Notably, a non-target subgroup can experience the largest degradation.

Fork and run

Create an account to run on Jetty. Free for your first 10 runs.

Run time2-5 mins

Version1.0.0

Agent + Model

claude-codeanthropic/claude-haiku-5.5

Example runs

Example 1

Default inputs

Mislabelling 30% of A1-B3's positives hurts A1-B4 most, 17.1% more than A1-B3 itself. The closed-form prediction matches the retrained ranking at Spearman 0.980. Synthetic data from the paper's generator. Logistic regression only, as in the paper.

Inputs

Target groupA1-B3

Flip fraction0.3

Heterogeneity0

N clients4

Beta-1,0.85,0.90,-0.70,0.55

R shift0.25

N seeds20

Acceptance checklist

15/15 checks passed.

Set up the sandbox and parameters
Extract the tested code
Run the experiment
Write the narrative
Render the result card and summary
The headline states this run's finding with its numbers, not a description of the method
Paper numbers are quoted exactly and any disagreement with the paper is stated plainly
Caveats say what is synthetic, reconstructed or an extension of the paper
Each try-next suggestion would plausibly give a contrasting result
Result card, numbers, narrative and summary were written
Experiment numbers are valid JSON and the experiment stayed within its time budget
The narrative is complete and within the length limits
Every try-next suggestion uses only this runbook's parameters
Every number in the headline appears in the run's results
The card embeds its figures, shows the headline, and contains no NaN

Published outputs

result_card.html results.json card_data.json narrative.json

System outputs

summary.md validation_report.json

Runbook

version	1.0.0
evaluation	programmatic
evals_version	2
agent	claude-code
model	anthropic/claude-haiku-5.5
model_provider	openrouter
snapshot	python312-uv
primary_outputs	result_card.html

Who Gets Hurt? Predicting Bias Propagation in Federated Learning (SMASH 2026 · Paper #16)

Objective

This runbook is an interactive companion to the SMASH 2026 paper "Tracing Bias Propagation Across Subgroups in Federated Learning" (Tirathraj Ramburn, Afaf Taïk, Farnoosh Ghadiri). Read the paper: https://drive.google.com/file/d/1aA6Fac9mYYJa1VoylGh4o3GgjQjDeobk/view?usp=sharing

The paper's question: in federated learning, if one hospital (client) systematically records false-negative labels for one patient subgroup, which subgroups at the other hospitals get hurt, and can we predict it without retraining? Its answer for logistic regression is a closed-form propagation vector

v_T = α_b · π⁺_{b,T} · H⁻¹ · μ⁺_{b,T} and predicted decrease L̂_{g,T}(ρ) = ρ · (μ⁺_g)ᵀ v_T

where α_b is the source client's weight, π⁺{b,T} the fraction of its training rows that are positive members of target subgroup T, μ⁺{b,T} their mean feature vector, H the Hessian of the shared training objective, ρ the fraction of target positives flipped to 0, and μ⁺_g the mean feature vector of a recipient group's positive cases. A recipient's damage depends on how far its mean projects along v_T, not on how similar it is to the source group, so the most-affected subgroup can be a different one entirely.

The participant chooses which subgroup is mislabelled, how badly, how different the clients are, and (optionally) the data-generating coefficients. The run simulates the paper's federation, predicts every recipient subgroup's damage with the formula, actually retrains to check it, and builds an audit matrix of all 8 possible source errors. Output: a shareable result card.

Target wall-clock: under 4 minutes. The experiment itself takes seconds.

Setup exactly as in the paper (§3, App. B)

4 equally weighted clients; each with 3,000 train / 3,000 validation / 8,000 test rows; seeds 0–19.
A ~ Bern(0.5); Z, W1, W2 ~ N(0,1); R | A ~ N(0.25(2A−1) + h·d_k, 1) with d = (0, −1, 0, 1); X = (1, Z, R, W1, W2); Y ~ Bern(σ(Xᵀβ)), β = (−1, 0.85, 0.90, −0.70, 0.55).
8 groups = A ∈ {0,1} × Z-quartile band B1–B4 (cuts −0.6745, 0, 0.6745). The model never sees A or group.
Only client 0's labels change (nested random subsets); λ = 1e−3 (intercept unregularized).
Training: FedAvg with full participation and one full-batch local step equals gradient descent on the weighted objective (paper App. B); this runbook solves that same objective with Newton's method (same optimum, faster).
Measured effect: mean (reference − retrained) logit over unchanged positive test cases at clients 1–3.
Agreement: Spearman rank correlation and zero-intercept slope c = ΣL·L̂ / ΣL̂²; 95% CIs from 2,000 whole-seed bootstraps.

Paper headline numbers (quote exactly)

IID, 30%: A1-B3 target → Spearman 0.975 [0.961, 0.987], c = 1.014; A0-B2 → 0.968 [0.955, 0.980], c = 1.016.
Heterogeneous: Spearman 0.931–0.974, c = 1.007–1.015; at h = 1, A1-B3 0.974, A0-B2 0.942.
Only 45.25 (A1-B3) / 27.20 (A0-B2) labels flipped per seed = 0.377% / 0.227% of 12,000 labels, yet every recipient mean decreased (480 and 2,880 group–client–seed means).
A1-B3 error → A1-B4 hit hardest (0.04225), 18.2% more than A1-B3 itself (ranks 2nd).
A0-B2 error → A1-B1 hit hardest (0.02679), 34.9% more than A0-B2 (ranks only 4th).
At h = 1, A1-B3 drops 0.02486 / 0.03441 / 0.04304 at clients 1 / 2 / 3; R-component of v_T is 0.03954 (A1-B3) vs 0.00047 (A0-B2).

REQUIRED OUTPUT FILES (MANDATORY)

All in {{results_dir}}:

File	Description
`result_card.html`	Primary output. Self-contained, shareable one-page result card
`results.json`	All computed numbers (written by `experiment.py`)
`card_data.json`	Numbers/figures for the card (written by `experiment.py`)
`narrative.json`	Your interpretation of this run (Step 4)
`fig_*.png`	Figures (written by `experiment.py`)
`summary.md`	5–10 line plain-text summary
`validation_report.json`	Evals v2 report: steps, code checks, checklist (see Write Validation Report)

Parameters

Parameter	Template Variable	Default	Description
Mislabelled subgroup	`{{target_group}}`	`A1-B3`	Source subgroup at client 0 whose positives get flipped: `A0-B1` … `A0-B4`, `A1-B1` … `A1-B4` (A = audit attribute, B = Z quartile band)
Flip fraction	`{{flip_fraction}}`	`0.3`	Fraction ρ of that subgroup's positive labels changed 1 → 0 (paper: 0.1–0.4)
Client heterogeneity	`{{heterogeneity}}`	`0`	h: shifts the mean of predictor R by h·(0, −1, 0, 1) across clients (paper: 0, 0.5, 1)
Clients	`{{n_clients}}`	`4`	Number of clients (2–8); client 0 is the source
Coefficients	`{{beta}}`	`-1,0.85,0.90,-0.70,0.55`	True β for (intercept, Z, R, W1, W2)
A→R association	`{{r_shift}}`	`0.25`	How strongly the audit attribute shifts predictor R (0 = A independent of features)
Seeds	`{{n_seeds}}`	`20`	Independent federations (paper: 20)

Dependencies

numpy and matplotlib (preinstalled in python312-uv). No downloads.

Step 1: Set up

mkdir -p {{results_dir}} /app/work && cd /app/work
python -c "import numpy, matplotlib" 2>/dev/null || uv pip install --system -q numpy matplotlib

Write /app/work/params.json (numbers as JSON numbers; if a value still looks like an unsubstituted {{…}} placeholder, use the default from the table):

{"target_group": "{{target_group}}", "flip_fraction": {{flip_fraction}}, "heterogeneity": {{heterogeneity}},
 "n_clients": {{n_clients}}, "beta": "{{beta}}", "r_shift": {{r_shift}}, "n_seeds": {{n_seeds}}, "runbook_url": ""}

Validate before running: target_group must be one of the 8 groups; clamp flip_fraction to [0.05, 0.9], n_clients to [2, 8], n_seeds to [5, 50]; beta must have 5 comma-separated numbers. Record any correction as a caveat.

Step 2: Get the code (extract it, don't retype it)

The tested implementation of the method is embedded in the Appendix at the end of this runbook. Do not rewrite, "improve", or re-derive it. Always run the command below first, exactly as written. It copies the files out of this runbook's text (which the sandbox exposes to running processes) in about a second, and it is far faster and more reliable than retyping several hundred lines. Do not skip it on the assumption that it won't work: run it and read its output.

cd /app/work && cat > extract.py <<'PYEOF'
"""Extract the runbook's embedded files without retyping them.

The runbook text reaches the agent as one command-line argument, so it is readable from /proc.
Every embedded file sits under a heading "### `/app/work/<name>`" followed by one fenced block.
Exits non-zero if any requested file can't be found, so the caller falls back to writing it by hand.

usage: python3 extract.py <name> [<name> ...]   (writes /app/work/<name>)
"""
import ast, glob, re, sys
from pathlib import Path

want = sys.argv[1:]
cands = []
for p in glob.glob("/proc/[0-9]*/cmdline"):
    try:
        s = Path(p).read_bytes().decode("utf-8", "ignore")
    except OSError:
        continue
    if all(f"### `/app/work/{w}`" in s for w in want):
        cands.append(s)
if not cands:
    sys.exit("runbook text not found in /proc; write the files by hand")
# The agent's own argv holds the raw text; wrapper shells hold a shell-quoted copy, so prefer the shortest
# and undo shell single-quote escaping as a fallback.
best = min(cands, key=len).replace("'\"'\"'", "'")
ok = True
for w in want:
    m = re.search(r"### `/app/work/" + re.escape(w) + r"`\s*\n+```[a-z]*\n(.*?)\n```\n", best, re.S)
    if not m or len(m.group(1)) < 50:
        print(f"MISSING {w}"); ok = False; continue
    code = m.group(1) + "\n"
    if w.endswith(".py"):
        try:
            ast.parse(code)
        except SyntaxError as e:
            print(f"MISSING {w} (extracted text does not parse: {e})"); ok = False; continue
    Path("/app/work", w).write_text(code)
    print(f"extracted {w}: {code.count(chr(10))} lines")
sys.exit(0 if ok else 1)
PYEOF
python3 extract.py experiment.py render_card.py validate.py

If it exits non-zero or prints MISSING, write each missing file from the Appendix exactly as given, one heredoc per file (quoted delimiter, e.g. cat > experiment.py <<'PYEOF'). If a later step fails, fix only environment problems (missing package, network retry), never the methodology.

Step 3: Run the experiment

cd /app/work && export OMP_NUM_THREADS=4 OPENBLAS_NUM_THREADS=4 MKL_NUM_THREADS=4 SMASH_CPUS=4 && timeout 240 python experiment.py params.json {{results_dir}}

Expected: a few seconds. Ends with a done: line.

The sandbox has 4 CPUs even though nproc may report more; the exports keep numpy/BLAS and process pools from oversubscribing them.

Step 4: Interpret: write `narrative.json`

Read {{results_dir}}/results.json and card_data.json, and look at every fig_*.png. Then write {{results_dir}}/narrative.json with keys headline, idea (exactly 3), findings (2–4), try_next (2–3), caveats (2–4):

headline (≤ 30 words): the most striking result of this run, with 1–2 numbers copied from results.json. Usually: who was hurt most vs. the mislabelled group, and how well the formula predicted it.
idea: the paper's contribution in plain language for a non-specialist audience (local label errors propagate through the shared model; a closed-form propagation vector predicts each recipient's damage without retraining; damage follows projection onto that vector, not similarity to the source).
findings: (1) did the prediction hold (Spearman, slope c, compared with the paper's numbers for the same target); (2) who was hurt most, and by how much more than the same-named group; (3) what the audit matrix says (audit_sources_whose_top_victim_is_another_group of 8; mention any negative predicted cells, meaning a recipient whose logit increases); (4) if h > 0 or β/r_shift changed, explain via the propagation vector components (propagation_vector) why clients or groups separate.
Use plain words: "logit decrease" = "the model's score for true positive cases dropped".
Be precise about agreement: Spearman < 1 means the predicted order is close to, not exactly, the measured order; say "closely predicted the ranking (Spearman …)", never "ranked all groups correctly".
try_next: 2–3 contrasting runs with exact values, using only the keys target_group, flip_fraction, heterogeneity, n_clients, beta, r_shift, n_seeds. Prefer ones where the audit matrix predicts a non-matching victim, or h = 1 with a target whose v_T has a large R component.
caveats: synthetic data; logistic regression only (the paper's linear setting); a lower logit does not necessarily flip a prediction; Newton solve in place of FedAvg rounds (same optimum).

Step 5: Render the card and summary

cd /app/work && python render_card.py {{results_dir}}/card_data.json {{results_dir}}/narrative.json {{results_dir}}/result_card.html

Write {{results_dir}}/summary.md (5–10 lines: settings, Spearman/c with CIs, most affected vs target, audit count, headline).

Writing style for narrative.json

These rules apply to every field and override any longer limits stated earlier in this runbook. Let the paper and the numbers speak; the card is not the place for commentary.

Length: headline one sentence; idea 1–3 bullets of at most 30 words; findings 1–2 paragraphs of at most 60 words each; caveats 1–2 bullets of at most 20 words. Cut anything the tiles, figures or tables already show.
Plain statements of what was measured. Write "Sensitivity gap −0.284 [−0.354, −0.218]; the paper reports +0.088", not an interpretation of what it means for the field.
Avoid: em-dash asides; "not X, but Y" framings; colon-then-reveal sentences; rhetorical questions; words such as crucially, notably, strikingly, remarkably, collapses, illustrating, underscores, highlights, delve, powerful, key insight, worth noting; exclamation marks; restating the method before the result.
Use the paper's own terms for its concepts. Quote the paper's numbers exactly.

Code Checks

Jetty runs these checks itself in the sandbox after the agent finishes, so they cannot be skipped or misreported. validate.py (see Write Validation Report) runs the same checks first so you can fix problems before you stop.

outputs-exist — Result card, numbers, narrative and summary were written

cd {{results_dir}} && for f in result_card.html results.json card_data.json narrative.json summary.md; do test -s "$f" || { echo "missing or empty: $f"; exit 1; }; done; echo "all 5 outputs present"

results-valid — Experiment numbers are valid JSON and the experiment stayed within its time budget

python3 - "{{results_dir}}" 240 <<'PY'
import json, sys
from pathlib import Path
R, budget = Path(sys.argv[1]), float(sys.argv[2])
res = json.loads((R / "results.json").read_text())
json.loads((R / "card_data.json").read_text())
rt = float(res.get("runtime_sec", 0))
if rt > budget:
    sys.exit(f"experiment took {rt}s, budget {budget}s")
print(f"results.json and card_data.json parse; experiment {rt}s within {budget:.0f}s")
PY

narrative-complete — The narrative is complete and within the length limits

python3 - "{{results_dir}}" <<'PY'
import json, sys
from pathlib import Path
n = json.loads((Path(sys.argv[1]) / "narrative.json").read_text())
problems = []
if not str(n.get("headline", "")).strip(): problems.append("no headline")
if len(str(n.get("headline", "")).split()) > 45: problems.append("headline over 45 words")
if not 1 <= len(n.get("idea", [])) <= 3: problems.append(f"idea has {len(n.get('idea', []))} bullets, need 1-3")
if not 1 <= len(n.get("findings", [])) <= 2: problems.append(f"{len(n.get('findings', []))} findings, need 1-2")
if any(len(f.split()) > 70 for f in n.get("findings", [])): problems.append("a findings paragraph is over 60 words")
if not 2 <= len(n.get("try_next", [])) <= 3: problems.append(f"{len(n.get('try_next', []))} try_next, need 2-3")
if not 1 <= len(n.get("caveats", [])) <= 2: problems.append(f"{len(n.get('caveats', []))} caveats, need 1-2")
if problems: sys.exit("; ".join(problems))
print("headline, %d idea bullets, %d findings, %d try_next, %d caveats" % (len(n["idea"]), len(n["findings"]), len(n["try_next"]), len(n["caveats"])))
PY

try-next-valid — Every try-next suggestion uses only this runbook's parameters

python3 - "{{results_dir}}" "target_group,flip_fraction,heterogeneity,n_clients,beta,r_shift,n_seeds" <<'PY'
import json, sys
from pathlib import Path
allowed = set(sys.argv[2].split(","))
n = json.loads((Path(sys.argv[1]) / "narrative.json").read_text())
bad = sorted({k for t in n.get("try_next", []) for k in (t.get("params") or {}) if k not in allowed})
empty = [t.get("label", "?") for t in n.get("try_next", []) if not t.get("params")]
if bad or empty: sys.exit(f"unknown parameters: {bad}; suggestions without params: {empty}")
print("all try_next parameters are declared runbook parameters")
PY

headline-grounded — Every number in the headline appears in the run's results

python3 - "{{results_dir}}" <<'PY'
import json, re, sys
from pathlib import Path
R = Path(sys.argv[1])
blob = (R / "results.json").read_text() + (R / "card_data.json").read_text()
vals = [float(x) for x in re.findall(r"-?\d+(?:\.\d+)?(?:[eE]-?\d+)?", blob)]
head = json.loads((R / "narrative.json").read_text())["headline"]
nums = re.findall(r"(?<![\w.−-])[−-]?\d[\d,]*(?:\.\d+)?(?![\w-])", head)
missing = []
for n in nums:
    s = n.replace("−", "-").replace(",", ""); v = float(s); dec = len(s.split(".")[1]) if "." in s else 0
    tol = 0.5 * 10 ** (-dec) + 1e-9
    if not any(abs(abs(x) - abs(v)) <= tol or abs(abs(x * 100) - abs(v)) <= max(tol, 0.5) for x in vals):
        missing.append(n)
if missing: sys.exit(f"headline numbers not found in results: {missing}")
print(f"{len(nums)} headline number(s) all grounded in results")
PY

card-integrity — The card embeds its figures, shows the headline, and contains no NaN

python3 - "{{results_dir}}" <<'PY'
import html, json, re, sys
from pathlib import Path
R = Path(sys.argv[1])
card = (R / "result_card.html").read_text()
head = json.loads((R / "narrative.json").read_text())["headline"]
problems = []
if re.search(r"\bNaN\b|\bnan%|\bInfinity\b", text): problems.append("NaN/Infinity in card text")
if len(card) > 5_000_000: problems.append(f"card is {len(card) // 1024} KB")
plain = html.unescape(re.sub(r"<[^>]+>", "", text))
if re.sub(r"[*`]", "", head)[:40] not in plain: problems.append("headline not on card")
if problems: sys.exit("; ".join(problems))
PY

Checklist

The headline states this run's finding with its numbers, not a description of the method
Paper numbers are quoted exactly and any disagreement with the paper is stated plainly
Caveats say what is synthetic, reconstructed or an extension of the paper
Each try-next suggestion would plausibly give a contrasting result

Write Validation Report

Judge the four Checklist items honestly against your outputs and write them to /app/work/checklist.json as a list, using the checklist ids Jetty gives you (one entry per item):

[{"id": "<checklist id>", "status": "pass", "message": "one line on why"}]

Then write the report and self-check in one command:

cd /app/work && python3 validate.py {{results_dir}} target_group,flip_fraction,heterogeneity,n_clients,beta,r_shift,n_seeds 240 checklist.json

validate.py writes {{results_dir}}/validation_report.json in the v2 shape Jetty reads (version: 2, one step entry per runbook step, one code_check entry per check above, one checklist entry per item). Jetty replaces the code_check entries with its own independent run of the same checks. Do not write the report by hand.

Iteration (up to 2 rounds)

If validate.py prints any FAIL, fix the named problem (usually a headline number that does not match results.json, or an unknown try_next key), re-render the card (Step 5) and rerun the command above. Never rerun the experiment just to change the narrative.

Appendix: code

These files are extracted verbatim in Step 2.

`/app/work/experiment.py`

"""Bias propagation in federated learning — SMASH 2026 paper #16 (Ramburn, Taïk).

Simulates the paper's synthetic federation, plants a false-negative labelling error in one
subgroup at client 0, predicts every recipient subgroup's mean logit decrease with the
closed-form propagation vector (no retraining), then retrains and checks the prediction.

usage: python experiment.py params.json outdir
"""
import json, sys, time
from pathlib import Path

import numpy as np
import matplotlib
matplotlib.use("Agg")
import matplotlib.pyplot as plt

T0 = time.time()
P = json.loads(Path(sys.argv[1]).read_text())
OUT = Path(sys.argv[2]); OUT.mkdir(parents=True, exist_ok=True)

K = int(P["n_clients"]); N_TR, N_VA, N_TE = 3000, 3000, 8000
LAM = 1e-3
BETA = np.array([float(x) for x in str(P["beta"]).split(",")])  # (intercept, Z, R, W1, W2)
R_SHIFT = float(P["r_shift"])          # R | A ~ N(r_shift (2A − 1), 1); paper: 0.25
H_SET = float(P["heterogeneity"])      # h; client offsets d = (0, −1, 0, 1, …)
TARGET = P["target_group"]             # e.g. "A1-B3"
RHO = float(P["flip_fraction"])
SEEDS = int(P["n_seeds"])
CUTS = (-0.6745, 0.0, 0.6745)
GROUPS = [f"A{a}-B{b}" for a in (0, 1) for b in (1, 2, 3, 4)]
FEATS = ["intercept", "Z", "R", "W1", "W2"]
D_OFF = np.array([0, -1, 0, 1, -0.5, 0.5, -1.5, 1.5])[:K]


def log(m):
    print(f"[{time.time() - T0:6.1f}s] {m}", flush=True)


def sigmoid(u):
    return 1 / (1 + np.exp(-u))


def make_client(rng, n, k):
    A = rng.binomial(1, 0.5, n); Z, W1, W2, eps = rng.standard_normal((4, n))
    R = R_SHIFT * (2 * A - 1) + H_SET * D_OFF[k] + eps
    X = np.c_[np.ones(n), Z, R, W1, W2]
    Y = rng.binomial(1, sigmoid(X @ BETA))
    band = np.searchsorted(CUTS, Z) + 1
    g = np.array([f"A{a}-B{b}" for a, b in zip(A, band)])
    return X, Y, g


def fit(Xs, Ys):
    """Minimise sum_k (alpha_k/n_k) sum_i logloss + (lam/2) th' D th  (paper Eq. 4) by Newton.
    FedAvg with full participation and one full-batch local step is gradient descent on this
    same objective (paper App. B), so the optimum is identical; Newton just gets there faster."""
    d = Xs[0].shape[1]; Dm = np.eye(d); Dm[0, 0] = 0
    th = np.zeros(d); a = 1 / len(Xs)
    for _ in range(50):
        g = LAM * Dm @ th; H = LAM * Dm.copy()
        for X, Y in zip(Xs, Ys):
            p = sigmoid(X @ th)
            g += a / len(Y) * X.T @ (p - Y)
            H += a / len(Y) * (X * (p * (1 - p))[:, None]).T @ X
        step = np.linalg.solve(H, g); th -= step
        if np.linalg.norm(g) < 1e-10:
            break
    return th, H


def spearman(a, b):
    ra, rb = np.argsort(np.argsort(a)), np.argsort(np.argsort(b))
    return float(np.corrcoef(ra, rb)[0, 1])


def run_seed(seed, target, rhos):
    rng = np.random.default_rng(seed)
    clients = [{"tr": make_client(rng, N_TR, k), "va": make_client(rng, N_VA, k), "te": make_client(rng, N_TE, k)}
               for k in range(K)]
    Xs = [c["tr"][0] for c in clients]; Ys = [c["tr"][1].copy() for c in clients]
    th0, H = fit(Xs, Ys)
    # source error at client 0: positives in target group, nested random order
    X0, Y0, g0 = clients[0]["tr"]
    elig = np.where((g0 == target) & (Y0 == 1))[0]
    order = rng.permutation(elig)
    pi_plus = len(elig) / N_TR
    mu_src = X0[elig].mean(0)
    v = (1 / K) * pi_plus * np.linalg.solve(H, mu_src)              # propagation vector (Eq. 2)
    out = {"v": v, "n_elig": len(elig), "by_rho": {}}
    for rho in rhos:
        m = int(round(rho * len(elig))); flip = order[:m]
        Y0c = Y0.copy(); Y0c[flip] = 0
        th_r, _ = fit(Xs, [Y0c] + Ys[1:])
        rho_eff = m / max(len(elig), 1)
        cells = []
        for k in range(1, K):
            for gname in GROUPS:
                Xv, Yv, gv = clients[k]["va"]; Xt, Yt, gt = clients[k]["te"]
                mu_g = Xv[(gv == gname) & (Yv == 1)].mean(0)
                pred = rho_eff * mu_g @ v                                  # Eq. 3
                sel = (gt == gname) & (Yt == 1)
                meas = float(np.mean(Xt[sel] @ (th0 - th_r)))
                cells.append({"client": k, "group": gname, "pred": float(pred), "meas": meas})
        out["by_rho"][rho] = {"cells": cells, "n_changed": m, "pct_of_federation": 100 * m / (K * N_TR)}
    # audit matrix: predicted decrease at every recipient group for every possible source group (no retraining)
    Xv = np.vstack([clients[k]["va"][0] for k in range(1, K)]); Yv = np.concatenate([clients[k]["va"][1] for k in range(1, K)])
    gv = np.concatenate([clients[k]["va"][2] for k in range(1, K)])
    mu_rec = {gname: Xv[(gv == gname) & (Yv == 1)].mean(0) for gname in GROUPS}
    audit = np.zeros((len(GROUPS), len(GROUPS)))
    for i, src in enumerate(GROUPS):
        e = np.where((g0 == src) & (Y0 == 1))[0]
        vs = (1 / K) * (len(e) / N_TR) * np.linalg.solve(H, X0[e].mean(0))
        audit[i] = [RHO * mu_rec[gname] @ vs for gname in GROUPS]
    out["audit"] = audit
    return out


def summarize(cells, iid):
    if iid:  # average recipient clients -> 8 group effects (paper's IID analysis)
        agg = {}
        for c in cells:
            agg.setdefault(c["group"], []).append(c)
        return [{"client": "1-%d" % (K - 1), "group": gname, "pred": float(np.mean([x["pred"] for x in v])),
                 "meas": float(np.mean([x["meas"] for x in v]))} for gname, v in agg.items()]
    return cells


def main():
    iid = H_SET == 0
    rhos = sorted(set([0.1, 0.2, 0.3, 0.4, RHO]))
    seeds = [run_seed(s, TARGET, rhos) for s in range(SEEDS)]
    log(f"{SEEDS} seeds fitted ({len(rhos) + 1} fits each)")
    per_seed = []
    for s in seeds:
        cells = summarize(s["by_rho"][RHO]["cells"], iid)
        pr = np.array([c["pred"] for c in cells]); me = np.array([c["meas"] for c in cells])
        per_seed.append({"spearman": spearman(pr, me), "c": float(me @ pr / (pr @ pr)), "cells": cells})
    rng = np.random.default_rng(0)
    def boot(key):
        vals = np.array([x[key] for x in per_seed])
        bs = [vals[rng.integers(0, len(vals), len(vals))].mean() for _ in range(2000)]  # whole-seed bootstrap
        return float(vals.mean()), [float(np.percentile(bs, 2.5)), float(np.percentile(bs, 97.5))]
    sp, sp_ci = boot("spearman"); c, c_ci = boot("c")
    # mean cell effects across seeds
    keys = [(x["client"], x["group"]) for x in per_seed[0]["cells"]]
    mean_cells = []
    for i, (k, gname) in enumerate(keys):
        pr = [ps["cells"][i]["pred"] for ps in per_seed]; me = [ps["cells"][i]["meas"] for ps in per_seed]
        mean_cells.append({"client": k, "group": gname, "pred": float(np.mean(pr)), "meas": float(np.mean(me)),
                           "meas_ci": [float(np.percentile(me, 2.5)), float(np.percentile(me, 97.5))]})
    ranked = sorted(mean_cells, key=lambda x: -x["meas"])
    top = ranked[0]
    # compare the most-affected cell with the target-matched group at the same recipient client (paper §4)
    tgt_best = [x for x in mean_cells if x["group"] == TARGET and x["client"] == top["client"]][0]
    all_pos = all(x["meas"] > 0 for ps in per_seed for x in ps["cells"])
    target_rank = 1 + [x["group"] for x in ranked if x["client"] == top["client"]].index(TARGET)
    v_mean = np.mean([s["v"] for s in seeds], 0)
    audit = np.mean([s["audit"] for s in seeds], 0)
    sweep = [{"rho": r, "pred": float(np.mean([np.mean([c["pred"] for c in summarize(s["by_rho"][r]["cells"], True)]) for s in seeds])),
              "meas": float(np.mean([np.mean([c["meas"] for c in summarize(s["by_rho"][r]["cells"], True)]) for s in seeds]))}
             for r in rhos]
    n_changed = float(np.mean([s["by_rho"][RHO]["n_changed"] for s in seeds]))
    pct = float(np.mean([s["by_rho"][RHO]["pct_of_federation"] for s in seeds]))
    most_hit_by_source = {GROUPS[i]: GROUPS[int(np.argmax(audit[i]))] for i in range(len(GROUPS))}
    n_self_not_top = sum(1 for k, v in most_hit_by_source.items() if k != v)
    res = {"params": P, "analysis": "IID (8 groups, recipients averaged)" if iid else f"heterogeneous h={H_SET} ({len(mean_cells)} client-subgroup cells)",
           "spearman": sp, "spearman_ci": sp_ci, "slope_c": c, "slope_c_ci": c_ci,
           "labels_changed_per_seed": n_changed, "pct_of_federation_labels": pct,
           "all_recipient_means_decreased": all_pos, "n_cell_seed_means": len(per_seed) * len(mean_cells),
           "most_affected": top, "target_matched_best": tgt_best, "target_rank": target_rank,
           "most_affected_is_target": top["group"] == TARGET,
           "most_affected_pct_more_than_target": float(100 * (top["meas"] / tgt_best["meas"] - 1)) if top["group"] != TARGET else 0.0,
           "propagation_vector": dict(zip(FEATS, map(float, v_mean))), "cells": mean_cells, "rho_sweep": sweep,
           "audit_matrix": {"sources": GROUPS, "recipients": GROUPS, "pred": audit.tolist()},
           "audit_most_hit": most_hit_by_source, "audit_sources_whose_top_victim_is_another_group": n_self_not_top}
    figures(res, mean_cells, sweep, audit)
    card(res)
    res["runtime_sec"] = round(time.time() - T0, 1)
    (OUT / "results.json").write_text(json.dumps(res, indent=2))
    log(f"done: spearman {sp:.3f} {sp_ci}, c {c:.3f}; most affected {top['group']} (target rank {target_rank})")


def figures(res, cells, sweep, audit):
    plt.rcParams.update({"font.size": 10, "axes.spines.top": False, "axes.spines.right": False})
    INK, A1, A0, MUTED = "#1f2a44", "#d9480f", "#1971c2", "#868e96"
    fig, ax = plt.subplots(figsize=(6.4, 4.2))
    mx = max(max(x["pred"] for x in cells), max(x["meas"] for x in cells)) * 1.12
    ax.plot([0, mx], [0, mx], ls="--", color=MUTED, lw=1)
    top = res["most_affected"]
    for x in cells:
        col = A1 if x["group"].startswith("A1") else A0
        mk = "*" if x["group"] == TARGET else ("D" if x is top or (x["group"] == top["group"] and x["client"] == top["client"]) else "o")
        ax.errorbar(x["pred"], x["meas"], yerr=[[x["meas"] - x["meas_ci"][0]], [x["meas_ci"][1] - x["meas"]]],
                    fmt=mk, color=col, ms=13 if mk == "*" else 7, alpha=0.9, elinewidth=0.8, capsize=0)
        if mk != "o" or len(cells) <= 8:
            lbl = x["group"] if len(cells) <= 8 else f"{x['group']} @c{x['client']}"
            ax.annotate(lbl, (x["pred"], x["meas"]), xytext=(5, 3), textcoords="offset points", fontsize=8)
    ax.set_xlim(0, mx); ax.set_ylim(0, mx)
    ax.set_xlabel("Predicted mean logit decrease (closed form, no retraining)")
    ax.set_ylabel("Measured decrease after retraining")
    ax.set_title(f"Spearman {res['spearman']:.3f} · slope c = {res['slope_c']:.3f}   (★ target {TARGET}, ◆ most affected)",
                 fontsize=9, loc="left")
    fig.tight_layout(); fig.savefig(OUT / "fig_pred_vs_meas.png", dpi=160); plt.close(fig)

    fig, ax = plt.subplots(figsize=(6.0, 4.8))
    lim = np.abs(audit).max()
    im = ax.imshow(audit, cmap="RdBu_r", vmin=-lim, vmax=lim)
    ax.set_xticks(range(8)); ax.set_xticklabels(GROUPS, rotation=45, ha="right", fontsize=8)
    ax.set_yticks(range(8)); ax.set_yticklabels(GROUPS, fontsize=8)
    for i in range(8):
        j = int(np.argmax(audit[i])); ax.add_patch(plt.Rectangle((j - .5, i - .5), 1, 1, fill=False, ec=INK, lw=1.6))
        ax.add_patch(plt.Rectangle((i - .5, i - .5), 1, 1, fill=False, ec=MUTED, lw=1, ls=":"))
    ax.set_xlabel("Recipient subgroup (clients 1…K−1)"); ax.set_ylabel(f"Source error at client 0\n({int(RHO * 100)}% of positives flipped)")
    fig.colorbar(im, ax=ax, fraction=0.046, pad=0.03, label="predicted logit decrease (red = hurt)")
    fig.tight_layout(); fig.savefig(OUT / "fig_audit_matrix.png", dpi=160); plt.close(fig)

    fig, axs = plt.subplots(1, 2, figsize=(6.4, 2.6), gridspec_kw={"width_ratios": [1.2, 1]})
    ax = axs[0]
    ax.plot([x["rho"] for x in sweep], [x["pred"] for x in sweep], "o--", color=MUTED, label="predicted")
    ax.plot([x["rho"] for x in sweep], [x["meas"] for x in sweep], "o-", color=INK, label="measured")
    ax.set_xlabel("Fraction ρ of target positives flipped"); ax.set_ylabel("Mean decrease"); ax.legend(frameon=False, fontsize=8)
    ax = axs[1]
    v = res["propagation_vector"]
    ax.bar(list(v)[1:], list(v.values())[1:], color=[A1 if x > 0 else A0 for x in list(v.values())[1:]])
    ax.axhline(0, color=INK, lw=0.8); ax.set_title("Propagation vector v_T", fontsize=9)
    fig.tight_layout(); fig.savefig(OUT / "fig_sweep_vector.png", dpi=160); plt.close(fig)


def card(res):
    top, t = res["most_affected"], res["target_matched_best"]
    iid = H_SET == 0
    where = lambda x: x["group"] if iid else f"{x['group']} at client {x['client']}"
    tiles = [
        {"label": "Rank agreement (Spearman)", "value": f"{res['spearman']:.3f}",
         "sub": f"95% CI [{res['spearman_ci'][0]:.3f}, {res['spearman_ci'][1]:.3f}] over {SEEDS} seeds", "tone": "good"},
        {"label": "Size agreement (slope c)", "value": f"{res['slope_c']:.3f}",
         "sub": f"1.0 = measured as large as predicted; CI [{res['slope_c_ci'][0]:.3f}, {res['slope_c_ci'][1]:.3f}]", "tone": "good"},
        {"label": "Most affected recipient", "value": where(top),
         "sub": ("the target-matched group itself" if res["most_affected_is_target"] else
                 f"{res['most_affected_pct_more_than_target']:.0f}% more than target {TARGET} (rank {res['target_rank']})"),
         "tone": "neutral" if res["most_affected_is_target"] else "warn"},
        {"label": "Labels changed", "value": f"{res['labels_changed_per_seed']:.1f}",
         "sub": f"{res['pct_of_federation_labels']:.3f}% of {K * N_TR:,} federation labels; "
                + ("every recipient mean decreased" if res["all_recipient_means_decreased"] else "not every mean decreased"),
         "tone": "accent"},
    ]
    inputs = {"source error": f"{int(RHO * 100)}% of {TARGET} positives → 0 at client 0", "clients": K,
              "heterogeneity h": H_SET, "β (1,Z,R,W1,W2)": P["beta"], "A→R shift": R_SHIFT, "seeds": SEEDS,
              "analysis": res["analysis"]}
    compare = [
        {"metric": "Spearman (IID, 30%)", "paper": "A1-B3: 0.975 [0.961, 0.987] · A0-B2: 0.968 [0.955, 0.980]",
         "yours": f"{res['spearman']:.3f} [{res['spearman_ci'][0]:.3f}, {res['spearman_ci'][1]:.3f}]", "note": "target " + TARGET},
        {"metric": "Slope c", "paper": "A1-B3: 1.014 · A0-B2: 1.016 (h=1: 1.009 / 1.007)", "yours": f"{res['slope_c']:.3f}", "note": ""},
        {"metric": "Most affected vs target", "paper": "A1-B3 → A1-B4 hit 18.2% more · A0-B2 → A1-B1 hit 34.9% more (target ranks 4th)",
         "yours": f"{where(top)}" + ("" if res["most_affected_is_target"] else f", {res['most_affected_pct_more_than_target']:.1f}% more (target rank {res['target_rank']})"), "note": ""},
        {"metric": "Labels changed (30%)", "paper": "A1-B3: 45.25 (0.377%) · A0-B2: 27.20 (0.227%)",
         "yours": f"{res['labels_changed_per_seed']:.2f} ({res['pct_of_federation_labels']:.3f}%)", "note": ""},
        {"metric": "Sources whose biggest victim is another group", "paper": "—  (new: audit matrix)",
         "yours": f"{res['audit_sources_whose_top_victim_is_another_group']} of 8", "note": "predicted, no retraining"},
    ]
    figs = [{"path": "fig_pred_vs_meas.png", "title": "Can we predict who gets hurt without retraining?",
             "caption": "Each point is a recipient subgroup: x = closed-form prediction ρ·μ⁺ᵀv_T, y = measured mean logit "
                        "decrease on unchanged positive test cases after actually retraining (mean and 95% range over seeds)."},
            {"path": "fig_audit_matrix.png", "title": "Audit without retraining: every possible source error",
             "caption": "Rows = which subgroup's positives are mislabelled at client 0; columns = recipient subgroups elsewhere. "
                        "Boxed = most-hit recipient; dotted = the same-named group. Off-diagonal boxes are the paper's warning."},
            {"path": "fig_sweep_vector.png", "title": "Linearity in ρ, and the direction of propagation",
             "caption": "Left: the measured effect grows ≈ proportionally with the flipped fraction, as Eq. 3 predicts. "
                        "Right: the propagation vector; recipients whose positive-case means project further along it lose more."}]
    Path(OUT / "card_data.json").write_text(json.dumps({
        "paper": {"num": 16, "title": "Tracing Bias Propagation Across Subgroups in Federated Learning",
                  "authors": "Tirathraj Ramburn, Afaf Taïk, Farnoosh Ghadiri", "url": "https://drive.google.com/file/d/1aA6Fac9mYYJa1VoylGh4o3GgjQjDeobk/view?usp=sharing", "affiliation": ""},
        "inputs": inputs, "tiles": tiles, "figures": figs, "compare": compare,
        "runbook": {"name": "smash-16-fl-bias-propagation", "url": P.get("runbook_url", "")}}, indent=2))


if __name__ == "__main__":
    main()

`/app/work/render_card.py`

"""Render a SMASH 2026 paper-playground result card (one self-contained HTML file).

usage: python render_card.py card_data.json narrative.json out.html

card_data.json  (written by the experiment script — numbers only)
  paper:   {num, title, authors, affiliation, url?}
  inputs:  {label: value}                         the participant's run settings
  tiles:   [{label, value, sub, tone}]            tone: accent|good|warn|neutral
  figures: [{path, title, caption}]               PNGs, embedded as base64
  compare: [{metric, paper, yours, note}]         paper-vs-your-run table (optional)
  runbook: {name, url}                            fork link (optional)
narrative.json  (written by the agent — words only)
  headline:  one sentence, the finding of THIS run
  idea:      [1-3 bullets] the paper's contribution in plain language
  abstract:  (optional) a verbatim abstract excerpt, shown instead of idea
  findings:  [2-4 short paragraphs] what this run shows, tied to the numbers
  try_next:  [{label, why, params}]               2-3 follow-up runs with exact parameter values
  caveats:   [bullets]
"""
import base64, html, json, sys
from pathlib import Path

data = json.loads(Path(sys.argv[1]).read_text())
narr = json.loads(Path(sys.argv[2]).read_text())
base = Path(sys.argv[1]).parent
e = lambda s: html.escape(str(s))


def md_inline(s):
    """Escape, then allow **bold**, *italic* and `code` only."""
    import re
    s = e(s)
    s = re.sub(r"\*\*(.+?)\*\*", r"<strong>\1</strong>", s)
    s = re.sub(r"(?<![\w*])\*(?!\s)(.+?)(?<!\s)\*(?![\w*])", r"<em>\1</em>", s)
    return re.sub(r"`(.+?)`", r"<code>\1</code>", s)


p = data["paper"]
tiles = "".join(
    f'<div class="tile {e(t.get("tone", "neutral"))}"><div class="tl">{e(t["label"])}</div>'
    f'<div class="tv">{e(t["value"])}</div><div class="ts">{md_inline(t.get("sub", ""))}</div></div>'
    for t in data.get("tiles", []))
# Columns that fill every row: 4 tiles as 2x2, never 3 + 1 orphan.
n_tiles = len(data.get("tiles", []))
tile_cols = 2 if n_tiles == 4 else min(max(n_tiles, 1), 3)
inputs = "".join(f'<span class="chip"><b>{e(k)}</b> {e(v)}</span>' for k, v in data.get("inputs", {}).items())
figs = ""
for f in data.get("figures", []):
    fp = Path(f["path"]); fp = fp if fp.is_absolute() else base / fp
    if fp.exists():
        b64 = base64.b64encode(fp.read_bytes()).decode()
        figs += (f'<figure><figcaption class="ft">{e(f.get("title", ""))}</figcaption>'
                 f'<figcaption>{md_inline(f.get("caption", ""))}</figcaption></figure>')
compare = ""
if data.get("compare"):
    rows = "".join(f'<tr><td>{md_inline(r["metric"])}</td><td>{md_inline(r["paper"])}</td>'
                   f'<td class="y">{md_inline(r["yours"])}</td><td class="n">{md_inline(r.get("note", ""))}</td></tr>'
                   for r in data["compare"])
    compare = (f'<section><h2>Paper vs. your run</h2><div class="tw"><table><thead><tr><th>Metric</th>'
               f'<th>Paper</th><th>Your run</th><th></th></tr></thead><tbody>{rows}</tbody></table></div></section>')
idea = "".join(f"<li>{md_inline(b)}</li>" for b in narr.get("idea", []))
abstract = narr.get("abstract", "")
findings = "".join(f"<p>{md_inline(x)}</p>" for x in narr.get("findings", []))
tries = "".join(
    f'<li><strong>{md_inline(t["label"])}</strong> — {md_inline(t.get("why", ""))}'
    f'<pre>{e(json.dumps(t.get("params", {}), ensure_ascii=False))}</pre></li>' for t in narr.get("try_next", []))
cav = "".join(f"<li>{md_inline(c)}</li>" for c in narr.get("caveats", []))
rb = data.get("runbook", {})
fork = (f'<a class="fork" href="{e(rb["url"])}">Fork this runbook on Jetty →</a>' if rb.get("url") else "")

page = f"""<!doctype html><html lang="en"><head><meta charset="utf-8">
<meta name="viewport" content="width=device-width,initial-scale=1">
<title>SMASH 2026 · #{e(p['num'])} · Result card</title>
<style>
:root{{--bg:#f6f4ef;--card:#fff;--ink:#1f2a44;--muted:#5c677d;--line:#e3dfd5;--accent:#d9480f;--good:#2b8a3e;--warn:#e67700;--chip:#efece4}}
@media (prefers-color-scheme:dark){{:root{{--bg:#11151f;--card:#1a2030;--ink:#e8ebf2;--muted:#9aa4b8;--line:#2c3447;--accent:#ff8a4c;--good:#69db7c;--warn:#ffc078;--chip:#232b3d}}
figure img{{background:#fff;border-radius:6px}}}}
*{{box-sizing:border-box}}body{{margin:0;background:var(--bg);color:var(--ink);font:15px/1.55 ui-sans-serif,system-ui,-apple-system,"Segoe UI",Roboto,sans-serif}}
main{{max-width:860px;margin:0 auto;padding:28px 16px 48px}}
.kicker{{font:600 12px/1 ui-monospace,SFMono-Regular,Menlo,monospace;letter-spacing:.08em;text-transform:uppercase;color:var(--accent)}}
h1{{font-size:clamp(22px,4vw,30px);line-height:1.2;margin:10px 0 6px}}.authors{{color:var(--muted);margin:0 0 18px}}.authors a{{color:var(--accent);text-underline-offset:3px}}
.headline{{background:var(--card);border:1px solid var(--line);border-left:5px solid var(--accent);border-radius:10px;padding:16px 18px;font-size:18px;font-weight:600;margin:0 0 18px}}
.chips{{display:flex;flex-wrap:wrap;gap:6px;margin:0 0 18px}}.chip{{background:var(--chip);border-radius:999px;padding:4px 10px;font-size:12.5px}}.chip b{{font-weight:600;color:var(--muted);margin-right:4px}}
.tiles{{display:grid;grid-template-columns:repeat(var(--cols),minmax(0,1fr));gap:10px;margin:0 0 22px}}
@media (max-width:560px){{.tiles{{grid-template-columns:1fr}}}}
.tile{{background:var(--card);border:1px solid var(--line);border-radius:10px;padding:12px 14px}}.tl{{font-size:12px;color:var(--muted);text-transform:uppercase;letter-spacing:.04em}}
.tv{{font-size:26px;font-weight:700;margin:2px 0;font-variant-numeric:tabular-nums}}.ts{{font-size:12.5px;color:var(--muted)}}
.tile.accent .tv{{color:var(--accent)}}.tile.good .tv{{color:var(--good)}}.tile.warn .tv{{color:var(--warn)}}
section{{background:var(--card);border:1px solid var(--line);border-radius:12px;padding:18px 20px;margin:0 0 16px}}
h2{{font-size:16px;margin:0 0 10px}}ul{{padding-left:20px;margin:0}}li{{margin:4px 0}}p{{margin:0 0 10px}}
figure{{margin:0 0 18px}}figure img{{width:100%;height:auto;display:block}}figcaption{{font-size:13px;color:var(--muted);margin-top:6px}}.ft{{font-weight:600;color:var(--ink);font-size:14px;margin:0 0 6px}}
.tw{{overflow-x:auto}}table{{border-collapse:collapse;width:100%;font-size:13.5px;font-variant-numeric:tabular-nums}}th,td{{text-align:left;padding:7px 8px;border-bottom:1px solid var(--line);vertical-align:top}}th{{color:var(--muted);font-weight:600}}td.y{{font-weight:600}}td.n{{color:var(--muted);font-size:12.5px}}
pre{{background:var(--chip);border-radius:6px;padding:6px 8px;font-size:12px;white-space:pre-wrap;word-break:break-word;margin:4px 0 8px}}code{{background:var(--chip);border-radius:4px;padding:1px 4px;font-size:.92em}}
.fork{{display:inline-block;background:var(--ink);color:var(--bg);text-decoration:none;font-weight:600;border-radius:8px;padding:10px 14px;margin-top:6px}}
footer{{color:var(--muted);font-size:12.5px;margin-top:22px}}
.abs{{margin:0;padding-left:14px;border-left:3px solid var(--accent);color:var(--ink)}}
</style></head><body><main>
<div class="kicker">SMASH 2026 · Paper #{e(p['num'])} · Result card</div>
<h1>{e(p['title'])}</h1><p class="authors">{e(p['authors'])}{(' · ' + e(p['affiliation'])) if p.get('affiliation') else ''}{(f' · <a href="{e(p["url"])}">Read the paper</a>') if p.get('url') else ''}</p>
<div class="headline">{md_inline(narr['headline'])}</div>
<div class="chips">{inputs}</div>
<div class="tiles" style="--cols:{tile_cols}">{tiles}</div>
{f'<section><h2>From the abstract</h2><blockquote class="abs">{e(abstract)}</blockquote></section>' if abstract else f'<section><h2>The idea</h2><ul>{idea}</ul></section>'}
{f'<section><h2>What this run shows</h2>{findings}</section>' if findings else ''}
<section><h2>Evidence</h2>{figs}</section>
{compare}
<section><h2>Try next</h2><ul>{tries}</ul>{fork}</section>
<section><h2>Read this before sharing</h2><ul>{cav}</ul></section>
<footer>Generated by a Jetty runbook built from the authors' SMASH 2026 paper. Numbers on this card come from code run in a sandbox; the words were written by an AI agent reading those numbers. This is an interactive companion, not the authors' own results unless labelled “Paper”.</footer>
</main></body></html>"""
Path(sys.argv[3]).write_text(page)
print(f"wrote {sys.argv[3]} ({len(page) // 1024} KB)")

`/app/work/validate.py`

"""Self-check a SMASH paper-playground run and write validation_report.json (evals v2 shape).

Runs the same checks as the runbook's `## Code Checks` (which Jetty re-runs independently after the agent
exits and substitutes for these entries), adds one `step` entry per runbook step and the agent's checklist
judgements, and prints PASS/FAIL lines.

usage: python validate.py <results_dir> <param,param,...> <budget_sec> [checklist.json]
"""
import html, json, re, sys
from pathlib import Path

R = Path(sys.argv[1])
allowed = set(sys.argv[2].split(","))
budget = float(sys.argv[3])
checklist_path = Path(sys.argv[4]) if len(sys.argv) > 4 else None


def load(name):
    try:
        return json.loads((R / name).read_text())
    except Exception:
        return None


res, cdata, narr = load("results.json"), load("card_data.json"), load("narrative.json")
card = (R / "result_card.html").read_text() if (R / "result_card.html").exists() else ""


def c_outputs_exist():
    missing = [f for f in ["result_card.html", "results.json", "card_data.json", "narrative.json", "summary.md"]
               if not (R / f).exists() or (R / f).stat().st_size == 0]
    return not missing, f"missing or empty: {missing}" if missing else "all 5 outputs present"


def c_results_valid():
    if res is None or cdata is None:
        return False, "results.json or card_data.json does not parse"
    rt = float(res.get("runtime_sec", 0))
    return rt <= budget, f"experiment {rt}s (budget {budget:.0f}s)"


def c_narrative_complete():
    if narr is None:
        return False, "narrative.json does not parse"
    p = []
    if not str(narr.get("headline", "")).strip(): p.append("no headline")
    if len(str(narr.get("headline", "")).split()) > 45: p.append("headline over 45 words")
    if not 1 <= len(narr.get("idea", [])) <= 3: p.append(f"idea has {len(narr.get('idea', []))} bullets, need 1-3")
    if not 1 <= len(narr.get("findings", [])) <= 2: p.append(f"{len(narr.get('findings', []))} findings, need 1-2")
    if any(len(f.split()) > 70 for f in narr.get("findings", [])): p.append("a findings paragraph is over 60 words")
    if not 2 <= len(narr.get("try_next", [])) <= 3: p.append(f"{len(narr.get('try_next', []))} try_next, need 2-3")
    if not 1 <= len(narr.get("caveats", [])) <= 2: p.append(f"{len(narr.get('caveats', []))} caveats, need 1-2")
    return not p, "; ".join(p) or "complete and within the length limits"


def c_try_next_valid():
    if narr is None:
        return False, "narrative.json does not parse"
    bad = sorted({k for t in narr.get("try_next", []) for k in (t.get("params") or {}) if k not in allowed})
    empty = [t.get("label", "?") for t in narr.get("try_next", []) if not t.get("params")]
    ok = not bad and not empty
    return ok, "all try_next parameters are declared" if ok else f"unknown parameters: {bad}; without params: {empty}"


def c_headline_grounded():
    if narr is None or res is None:
        return False, "missing narrative or results"
    blob = json.dumps(res) + json.dumps(cdata or {})
    vals = [float(x) for x in re.findall(r"-?\d+(?:\.\d+)?(?:[eE]-?\d+)?", blob)]
    nums = re.findall(r"(?<![\w.−-])[−-]?\d[\d,]*(?:\.\d+)?(?![\w-])", narr.get("headline", ""))
    missing = []
    for n in nums:
        s = n.replace("−", "-").replace(",", ""); v = float(s); dec = len(s.split(".")[1]) if "." in s else 0
        tol = 0.5 * 10 ** (-dec) + 1e-9
        if not any(abs(abs(x) - abs(v)) <= tol or abs(abs(x * 100) - abs(v)) <= max(tol, 0.5) for x in vals):
            missing.append(n)
    return not missing, f"not found in results: {missing}" if missing else f"{len(nums)} headline number(s) grounded"


def c_card_integrity():
    if not card or narr is None:
        return False, "no card or narrative"
    plain = html.unescape(re.sub(r"<[^>]+>", "", text))
    p = []
    if re.search(r"\bNaN\b|\bnan%|\bInfinity\b", text): p.append("NaN/Infinity in card text")
    if len(card) > 5_000_000: p.append(f"card is {len(card) // 1024} KB")
    if re.sub(r"[*`]", "", narr.get("headline", ""))[:40] not in plain: p.append("headline not on card")


CODE_CHECKS = [  # ids and names match the runbook's ## Code Checks headings
    ("outputs-exist", "Result card, numbers, narrative and summary were written", c_outputs_exist),
    ("results-valid", "Experiment numbers are valid JSON and the experiment stayed within its time budget", c_results_valid),
    ("narrative-complete", "The narrative is complete and within the length limits", c_narrative_complete),
    ("try-next-valid", "Every try-next suggestion uses only this runbook's parameters", c_try_next_valid),
    ("headline-grounded", "Every number in the headline appears in the run's results", c_headline_grounded),
    ("card-integrity", "The card embeds its figures, shows the headline, and contains no NaN", c_card_integrity),
]
STEPS = [  # (id, name, evidence that the step happened)
    ("setup", "Set up the sandbox and parameters", Path("/app/work/params.json").exists() or res is not None),
    ("get-code", "Extract the tested code", Path("/app/work/experiment.py").exists() or res is not None),
    ("experiment", "Run the experiment", res is not None),
    ("interpret", "Write the narrative", narr is not None),
    ("render", "Render the result card and summary", bool(card) and (R / "summary.md").exists()),
]

checks = [{"kind": "step", "id": i, "name": n, "status": "pass" if ok else "fail"} for i, n, ok in STEPS]
for cid, name, fn in CODE_CHECKS:
    try:
        ok, msg = fn()
    except Exception as e:  # a check that crashes is an error, never a silent pass
        ok, msg = None, f"{type(e).__name__}: {e}"
    status = "pass" if ok else ("error" if ok is None else "fail")
    checks.append({"kind": "code_check", "id": cid, "name": name, "status": status, "message": str(msg)[:1000]})
    print(f"{'PASS' if ok else 'FAIL'} {cid}: {msg}")

if checklist_path and checklist_path.exists():
    for item in json.loads(checklist_path.read_text()):
        st = item.get("status", "skipped")
        st = st if st in ("pass", "fail", "skipped", "error") else "skipped"
        checks.append({"kind": "checklist", "id": str(item["id"]), "name": str(item.get("name") or item["id"]),
                       "status": st, "message": str(item.get("message", ""))[:1000]})
        print(f"{'PASS' if st == 'pass' else 'FAIL'} checklist {item['id']}: {item.get('message', '')}")
else:
    print("NOTE no checklist.json given; checklist items will be recorded as not reported")

gating = [c for c in checks if c["kind"] != "step"]
verdict = "fail" if any(c["status"] in ("fail", "error") for c in gating) else ("pass" if gating else "unknown")
(R / "validation_report.json").write_text(json.dumps({"version": 2, "verdict": verdict, "checks": checks}, indent=2))
print(json.dumps({"verdict": verdict, "passed": sum(c["status"] == "pass" for c in gating), "gating_checks": len(gating)}))
